Start to design the HTML structure of the header section of the page. You will use CSS grid to contain the content and set the size and spacing of the elements.

We'll learn how to build a layout in Tailwind by creating a centered container with max width, and add some space between elements.

Creating Layouts with Flexbox and Grid

[00:00] All right, so I'll start by defining our container with multiple sections here. And so these are the two layout containers that we've created in the previous lesson. And here is the common parent to all our content section over here. Here we can add class names. And like we did before, we could use grid here.

[00:19] And let me turn on the grid line, so we see what we're doing. But this time we want to turn on the new grid, this one. And maybe I'll turn off the other ones. And let me refresh the page to have a different color. Yep, I like that one. Fun fact, in Chrome, every time you refresh the page, the grid lines show up with a different color. And we could handle a section like this,

[00:36] but you can also use flexbox if you prefer. So I could change this to flex. Obviously, this is going to stack stuff horizontally, but then I can go flex col to make it vertical. Once again, we can turn on some visual helpers from the dev tools for the flex container. And that will work mostly the same. I would myself use grid most of the time.

[00:56] I always have that rule that if something has a predictable amount of space it needs to use, I like to use grid. But if I want something to flow and use whatever space it needs, usually I reach for flexbox for something that kind of spreads and then the next element goes after it and uses the space that it needs in a more fluid way.

[01:14] Regardless of the approach, flex or grid, what we want to do is now horizontally center our elements. And so here in the flexbox context, we've switched to flex col. So the way to horizontally center things is with align items. So I can go items center, and this should put things in the center.

[01:32] Now you can see that the paragraph is actually left aligned, but it's completely normal because our paragraph is actually taking the whole width and then the text inside it is left aligned. If we look at the H1, it's not using the full width, but if that text was much longer, the exact same thing would happen. The element would span across the whole width and then left align.

[01:51] So what we need to do to guard against this, and we don't really know the length of the headline or the paragraph. So maybe on the parent element, we want to align the text center. We could do this on the H1 and the P tag, but instead we can do it on the common parent here, text center,

[02:08] and this will center the text itself within the element. And so no matter how long it is, it'll look centered. I can remove my gibberish here on the heading, and you can see we are at a nice place. We're going to take another sneak peek into the future and into the bigger screens, just to realize that something happened

[02:28] to this content section. It seems to be max width clamped to a width of 448 pixels width. You can see, even when the screen gets larger, we don't have a width going larger than 448. And this kind of makes sense. We don't really want the paragraph tag

[02:46] to be super long on one line because it looks kind of weird. And so there's this max width container here to guard it. And we should probably do the same because right now, if I make the screen larger, you can see that the paragraph will go on one line, and if the text was longer, it would keep growing and growing. And so we're going to try to respect

[03:05] this max width of 448 pixels, and we can go for a max width on the wrapper here, max width, and you can see the numbers here growing. We have all these options, but we also have small, medium, and what do you know? Medium is 448 pixels exactly.

[03:25] I guess the designers have looked at the values in the tailwind theme and kind of tried to play with it. Good job. That makes our job easy. So now if I save this and I go wide, once again, it should stop growing after it reaches this max width MD, which is perfect. And with that, we have style our container. It has a max width.

[03:45] It is horizontally centered, so we can get rid of all of that. And now we can focus on the next thing, which is the typography and spacing between elements. When you think about spacing in the context of flex or grid, your mind might instantly go to the gap property, which is super useful. But here, look at what happens.

[04:04] The spacing or the gap between the first two elements and the next two is not the same. We have 24 pixels between the logo and the heading, and then 16 pixels only between here and there. So we could have a gap of 16 and then add a margin top to compose with the gap, but I think it's a little bit messy.

[04:23] And honestly, if the values are different between each element and we don't have more than once the same, I think we can handle the spacing internally. So we can apply some padding or margin to the elements themselves, and that's what we're gonna do. I will leave the first element intact, and then I will add a margin top of 24 pixels,

[04:41] which is a level of six in tailwind. And then here to have 16, we'll have empty four on the paragraph. So on the H1, class name equals empty six, which is 24 pixels. And then on the paragraph tag, class name equals empty dash four.

[05:00] And now we have the correct amount of spacing applied via a margin, which is great. So the last thing we need to worry about is the font size, font weight, font color, et cetera, and we should be good to go. And just to make sure, the logo here is set to size 20,

[05:18] which is 80 pixel by 80 pixel. So let's just quickly verify that that's the case. And yep, 80 by 80 is what we want here, so we're good. So the font size, let me make sure that I am actually in the mobile version, I am. So here the font size is 36 pixels, line height 40,

[05:36] and the font weight is 500. So 36 pixels. After my margin here, I'll go text, and let's go to the sizes. So base is 16 pixels, LG is 18, we gotta go to 36. And look at this, text for Excel is 36 pixels and 40 pixels line height, exactly like we want.

[05:56] And then we can change the font weight with font, and you can see a thin, extra light, and we want 500, which is font medium light. So in terms of colors, I believe this is black and highlights, so we should be good to go. Yep, black and highlights. And so next for the paragraph at the mobile screen,

[06:14] it looks like the font size is the base size, 16 pixels by 24 line height, which is also Tailwind's default. The font weight is 400, which is also the default, but we need to change the color. So the link itself is black, but then the text has that custom color here, which is the light gray.

[06:34] And if you remember from defining colors, it is actually mapped to Tailwind's slate 600. You can see the matching hex numbers here. So we can essentially set our text color to slate 600, and then the anchor tag inside of it should be black. And we also, while we're there,

[06:54] make sure that it's underlined. All right, let me remove these comments that are confusing more than anything at this point. We know what we're trying to do. Just this one, apply the correct text color. Don't worry about the hover state for now. So we will do the hover style of the link later. So we'll just make it look like it should on idle state when it's not being interacted with.

[07:13] So the text color will be text slate, remember 600, but then inside of it, the anchor tag will have a text of black. And finally, we want also this link to be underlined. And this brings us in a really good place. Our content section in the design and our content section in the code

[07:32] are looking very, very similar. This gives me a lot of confidence that if we happen to do a screenshot test where we overlay the Figma design over a browser rendering, we should have a perfect match. And with that, we can move to the next step, which is styling the list item, the logo tiles here.

Implementing the Content Section

[00:00] Time has come to focus on the actual design. We're going to dive in the content section here, so the logo, heading, and paragraph, and start making things look as close as we can to the design. As you can probably tell, as I hover over things, you can see the spacing. It looks like we

[00:15] have some sort of container here, and you probably might want to use Grid or Flexbox to achieve this. So start by starting this content section container. Remember, we've wrapped these elements inside a div in the previous exercise, and then make sure that everything has the right size, font size, font weight, spacing, etc. Good luck with that, and I'll see you in the

[00:35] next video to show you how I would do this.

This workshop is designed to help you achieve 'pixel-perfect' design implementations, bridging the fidelity gap between design and development. Throughout this workshop, you’ll be guided along essential steps—from analyzing Figma designs to implementing responsive layouts and learn advanced CSS techniques.

## Project Setup

Before implementing Tailwind in your website, it's essential to set up and analyze the provided Figma design file. This ensures alignment with design elements and sets a solid foundation for your project. By analyzing and preparing the Figma design file upfront, you streamline development and ensure your Tailwind website reflects the intended design accurately.

- Semantic HTML structure
- Color and typography integration

## Mobile First

Prepare to bring your landing page design to life by focusing first on its mobile implementation, guided by insights from the Figma design file. Understanding the mobile layout is crucial before scaling up to larger screens. You'll dissect the mobile design into key segments: the content section featuring the logo, heading, and paragraphs; the arrangement of logo tiles; and the overall structural layout. By analyzing how these elements evolve across breakpoints, you'll gain a clear strategy for organizing your page effectively.

## Responsive Design

Ensure your website maintains consistent quality across all screen sizes by implementing precise design adjustments specified at different breakpoints.

- Current layout strength
- Design-Specific adjustments
- Attention to detail
- Tools for precision

## Art Directed Grid

CSS Grid provides a powerful feature that allows you to place elements in specific grid cells according to your design. By learning the placement of elements in a CSS Grid, you'll be able to create intricate and visually appealing designs with ease.

- Grid cell placement
- Precision positioning
- Create complex layouts

## Interaction

Add interaction styles to the application to clearly indicate interactive elements such as links and logo tiles. The goal is to closely recreate the designs specified in the Figma file to enhance the user experience and clearly indicate which elements are interactive within the application.

- Implementing hover states for links
- Defining focus states using Tailwind's outline and ring utilities
- Ensuring the implemented styles match the designer's vision

## Animation

Explore how to add engaging animations by to our user interface using exclusively CSS keyframe animations.

- Implementing a visually appealing role reveal effect on logo tiles
- Creating a staggered animation delay for a stunning waterfall entry effect
- Respecting users' preferences by providing a simple fade-in alternative for those who prefer reduced motion
- Ensuring accessibility by considering users with motion sensitivity

## Subgrid Alignment

CSS subgrid is a powerful feature that aligns a nested grid with its parent grid's cells. This section demonstrates its effectiveness in a specific design scenario, illustrating how it enables precise alignment and layout control.

## Migrate to Tailwind v4

Discover the enhanced flexibility of Tailwind CSS version 4, which introduces a streamlined method for configuring your theme directly in CSS using CSS variables. This update simplifies the customization process compared to the previous reliance on JavaScript config files.


Learn to implement 'pixel-perfect' designs from Figma with responsive layouts, advanced CSS techniques, and Tailwind v4 migration in this workshop.

Pixel Perfect Tailwind

Simon Vrachliotis

Pixel Perfect Figma to Tailwind

Welcome to the Pixel Perfect Tailwind Workshop. We'll implement a real-world redesign of the EpicStack website homepage from scratch using Figma design specs and tailwind. We'll cover tailwind theme configuration, design implementation, hover and focus states as well as some fun animations and CSS Grid techniques.

Pixel Perfect Tailwind Workshop Introduction

Introduction

exploring the design file and extracting the information we need to get started.

Preparing for a Custom Design

In this lesson, we'll use Figma to design the semantic structure of the Epic Stack homepage and then write the corresponding React markup in a Vite-powered site.

In this lesson, we'll add the HTML that will serve as the basis for our page. We'll import the logos from data and add the corresponding markup to the page. We'll also see how to use the size utility to ensure the logo has a good size on the page without having to specify both the width and the height.

Functional and Semantic Markup

Unstyled Markup

Learn how to configure Tailwind's theme to create bespoke, project-specific utilities that reflect your design system.

Tailwind config to change the breakpoints, colors and the font family and size as specified by our designer in Figma.

Customizing Tailwind CSS Configuration for a Responsive Design

Tailwind Theme Customization and Configuration

Learn how to build a website from scratch using the utility-first CSS framework Tailwind. This lesson covers setting up the basic HTML structure of the website.

The Foundation is Built

Project Setup

In this exercise, you will learn how to use Figma to design the mobile version of the page and then replicate the design in HTML/CSS with Tailwind. We will look at the structural layout of the design and how to break it down into HTML components. We will also look at the typography and how to replicate it with Tailwind.

Designing for Mobile First

 We will create a basic page layout using the `div` wrappers and see how they can be used to define the structure of the page.

 We'll start with the `min-h-screen` class to create a full page container, then we'll add some padding using the `px` and `py` utility classes.

Dynamic Layout Containers

Structural Layout

In this lesson, you will recreate the logo list design using CSS grid. Pay attention to the max width container and the gaps between elements.

use Tailwind to build a responsive design for a component that will scale with the width of the container.

Styling Lists with Flexbox & Grid

Building a Responsive Logo

You've done an amazing job so far! Take a break and get ready for the next challenge.

Mobile Layout Completed

Mobile First

Designers make changes to spacing, color, and more as the design scales up and down. We'll learn how to identify these changes and implement them in our code.

Identify Design Changes Across Breakpoints in Figma

learn how to use the `Typography` component to ensure that the font sizes of your headings and paragraphs are responsive.

Learn how to use Tailwind's utility classes to make responsive typography adjustments for headings and paragraphs.

Responsive Typography

Implementing Responsive Typography

In this lesson, you will learn how to use the spacing scale to manage the spacing around and between elements.

Importance of breaking out design into components when working on a responsive design.

Responsive Spacing

Spacing Around and Between Elements

At the Excel breakpoint we want to place the contents section on the right and the tiles on the left. We will use the grid to define the column widths.

Learn how to create a two column layout with auto-sizes and one fraction units, use the `order` feature to invert the order of the grid cells.

Responsive Grid Layouts

Creating Responsive Two-Column Layouts

refactor our flexbox layout to use the CSS Grid layout, create a grid with 5 columns and 6 rows and change the tile flow

We will cover the simple process of switching from flexbox to css grid, changing the grid structure, and changing the auto flow direction.

Responsive Grids with Auto Flow Columns

Building a Structured Grid Layout

It's time for a break! We've covered a lot of material so far and it's time to recharge before we dive into some exciting stuff.

Responsive Design Completed

Responsive Design

CSS Grid allows us to place items in specific grid cells. This lesson walks through the syntax to get items placed.

Place Items in a Grid

Learn how to use CSS grid lines as a coordinate system to place grid elements exactly where you want them to be inside the grid with Tailwind.

In this lesson, we will add a `column` and `row` property to each logo object, and use these properties to position each logo in the top left of the grid.

Adding Grid Coordinates to Logo Objects

Assign Coordinates to Elements

In this exercise, you will use the lookup directory pattern to dynamically compose grid classes based on an object’s values.

Leverage the power of TypeScript and dynamic styles to create a simple yet flexible grid system with Tailwind.

Dynamic Grid Placement

Lookup Objects for Grid Placement

This section walks through how to use the utility-based approach of Tailwind to build out a simple landing page

Pixel Perfect Grid Completed

Art Directed Grid

Learn how to use the hover, focus, and active states to improve the interactivity of links in your application by applying the design specified in the Figma file.

Adding Interaction Styles

Learn how to apply the hover and focus states for links by adding the hover "hover" and focus "focus" class to the link.

In this lesson, we’ll use Tailwind to remove the underline on

Accessibility with Focus and Hover Styles

Styling Text Interactions

In this lesson, you will learn how to style the logo tiles on hover and focus using the CSS `

In this lesson, you will learn how to use the utilities in Tailwind to completely customize the

Customizing Hover and Focus Styles

Logo Interaction Styling

create a simple page layout using the Grid layout. We'll use the `display grid` and `display inline-grid` properties to define grid containers and grid items.

Interactions Completed

Interaction

create a series of cool animations without forgetting about users who have set `prefers-reduced-motion` media query in their OS settings.

Creating Engaging UI Animations

Learn how to create a keyframe animation in Tailwind and apply it to any element in your markup.

Controlling Animation Delays and Fill Modes

Add an Enter Animation

In this exercise, you will learn how to set a responsive animation keyframe that will be applied at a specific breakpoint.

We'll create a new keyframe animation for the slide left and update our config to support it. We'll then apply the animation based on the Excel breakpoint.

Responsive Animations

Change Animations Based on Breakpoints

Learn how to create a cool logo reveal animation using keyframes and easing curves, leverage the open props library for advanced spring easing curves.

Learn how to create a reveal animation in Tailwind using Open Props.

Roll Reveal and Fade-In Keyframe Animations

Implementing Roll Reveal Effect

Learn how to use the CSS `animation-delay` property to create a staggered reveal effect.

learn how to create an animated stagger effect using CSS and a render prop.

Delayed Animations Based on Loop Index

Adding Stagger Reveal to Animations

In this lesson, we'll add a small delay to the first keyframe so that the animation doesn't steal the focus from the rest of the page loading animation.

In this lesson, we'll add an animation delay to the logo and heading elements to create a balanced look in the Epic Stack animation.

Implementing a Wave Animation Delay

Animation Delay Adjustment

In this lesson we'll use the subgrid to align two grid components on the same level.

Animations Completed

Animation

Subgrid is a CSS feature that allows grid tracks to function as a subgrid to their parent grid. This can be used to create amazing layouts that lock and align grid cells.

Aligning Grids to Parent Cells

Subgrid is a feature that allows child grids to inherit the grid structure of their parent grid.

In this lesson, we'll see how to span grid cells across the parent grid, and also how to align the gap values between the parent grid and the child grid.

Managing Nested Grids for Organized Layouts

Fixing Vertical Gap in a Subgrid

In this lesson, you will learn how to align grids within grids by matching the gap on the child grid with the gap on the parent grid.

By applying the `gap` property to the parent grid and controlling the row gaps, you can ensure that the grid children are properly spaced.

Adjusting Grid Gaps for Seamless Alignment

Child and Parent Grid Alignment

In this lesson, we use CSS grid to create a subgrid and align our content elements. This allows us to easily position them within our layout.

In this lesson, we will restructure our content section to use CSS grid and position it with grid columns and rows.

Managing Rows and Columns in Responsive Grid Layout

Aligning Elements with Parent Grid Using Subgrid

Learn how to use the grid system in Tailwind to organize content on the page, refactor the design to place the logo and heading tag on the same row.

Learn how to use the CSS Subgrid feature in Tailwind by building a two column grid within a subgrid.

 Responsive Grid Columns

Content Placement with the Grid Layout

In this lesson, you will learn how to vertically and horizontally center content within a grid cell.

We'll see how to use `grid-template-rows` and `grid-template-columns` to place content in a subgrid

Optimizing Grid Layouts

Aligning Content Within Cells

Learn how to bring your CSS modules from Tailwind v1, v2, or the css in js output of bit styles to Tailwind v4.

Subgrids Completed

Subgrid Alignment

configure Tailwind version 4 using CSS custom properties. we'll take all of the config we've created in JavaScript and move it to CSS using CSS variables.

Migrate Tailwind v3 to v4

Tailwind v4 can be installed in several ways. In this lesson, you will install the Tailwind Vite plugin.

In this lesson, learn how to use Tailwind v4 with Vite. We will take a look at the Vite plugin for Tailwind and how it can simplify the configuration.

Upgrading to Tailwind v4 with Vite Plugin

Integrating Tailwind v4 with Vite

Learn how to customize the Tailwind theme by applying direct changes to the CSS config file.

Learn how to use the design token file to configure Tailwind's colors, font sizes, and custom breakpoints without leaving the CSS syntax you're used to.

Customizing Your Design with Tailwind Configuration

Customize the Tailwind Theme

LESS has a powerful feature that allows you to define object key and value pairs inline. This allows you to define multiple styles at the same time.

Learn how to use CSS variables with the designer tool Copilot to ensure consistency in your design system.

Custom Font Sizes and Line Heights

Fixing Font Sizes

Learn how to apply CSS animations and keyframe animations to React components to create smooth slide animations and reveal animations.

Tailwind version 4 introduces a lot of changes that make it easier to customize and maintain your project.

Porting Keyframes and Animations

Revamping Animations

Learn how to convert a Tailwind config from JavaScript to the new CSS config in v4.

Tailwind v4 Migration Complete

Preparing for Tailwind v4

The next time you're tasked with converting a design to Tailwind, you can go through the same process of doing multiple passes from mobile to desktop, each time focusing on something different to make sure nothing goes through the cracks and end up with a really high-quality result.
